The PHW pressure washer series combines durability and advanced features like patented Cool-Bypass technology to prevent pump overheating, Snap ‘N Go upgrade kits, a large diesel fuel capacity, and an integrated detergent system for efficient, uninterrupted industrial cleaning tasks.
CALL FOR PRICING: 563-299-4887
PRESSURE (PSI)
FLOW (GPM)
VOLTS
PHASE
AMPS
HORSEPOWER
This workhorse has been a flagship for more than a quarter of a century, and now has patented Cool-Bypass technology that limits temperature buildup in the pump during periods of inactivity, prolonging the life of the equipment. Another innovation introduced to an already long list of features is Snap ‘N Go kits, which allow easy upgrades to time delay shutdown, wireless remote operation, or auto start-stop. This industrial series includes our large frame LT Pump affixed to our proprietary Tru-Trac belt tension system, and an oversized 10-gallon diesel fuel capacity allows you to complete challenging cleaning jobs without interruption. The integrated float tank and metering valve allows for the easy introduction of detergents when needed. Whether cleaning hog confinements, farm equipment, or fleet vehicles, the PHW series is built to deliver top quality results.
The following information includes all Landa PHW models available from Landa with varying gallons per minute and pressure. When placing an order, please refer to this information and include the model number. Additional parts and accessories can be added to most pressure washers, such as spray wands and triggers, pressure washer nozzels, and pressure washer hoses, etc.
| Model No. | GPM | PSI | MOTOR HP | VOLTS | PHASE | AMPS | WEIGHT | DIMENSIONS |
|---|---|---|---|---|---|---|---|---|
| PHW3-11024D | 2.8 | 1,000 | 2.0 | 120 | 1 | 20 | 590 lbs | 52"L x 32"W x 38"H |
| PHW4-22024A | 4.0 | 2,200 | 6.2 | 230 | 1 | 29 | 625 lbs | 52"L x 32"W x 38"H |
| PHW4-22024B | 4.0 | 2,200 | 6.2 | 230 | 3 | 19 | 610 lbs | 52"L x 32"W x 38"H |
| PHW4-22024C | 4.0 | 2,200 | 6.2 | 460 | 3 | 11 | 615 lbs | 52"L x 32"W x 38"H |
| PHW4-22024F | 3.5 | 2,200 | 5.0 | 575 | 3 | 10 | 615 lbs | 52"L x 32"W x 38"H |
| PHW4-22024G | 4.0 | 2,200 | 6.2 | 208 | 1 | 31 | 625 lbs | 52"L x 32"W x 38"H |
| PHW4-22024H | 4.0 | 2,200 | 6.2 | 208 | 3 | 21 | 610 lbs | 52"L x 32"W x 38"H |
| PHW-30024A | 3.9 | 3,000 | 8.2 | 230 | 1 | 38 | 640 lbs | 52"L x 32"W x 38"H |
| PHW-30024B | 3.9 | 3,000 | 8.2 | 230 | 3 | 24 | 625 lbs | 52"L x 32"W x 38"H |
| PHW-30024C | 3.9 | 3,000 | 8.2 | 460 | 3 | 12 | 635 lbs | 52"L x 32"W x 38"H |
| PHW-30024F | 3.5 | 3,000 | 7.5 | 575 | 3 | 12 | 635 lbs | 52"L x 32"W x 38"H |
| PHW-30024G | 3.9 | 3,000 | 8.2 | 208 | 1 | 40 | 640 lbs | 52"L x 32"W x 38"H |
| PHW-30024H | 3.9 | 3,000 | 8.2 | 208 | 3 | 26 | 625 lbs | 52"L x 32"W x 38"H |
| PHW5-30024B | 4.8 | 3,000 | 10.0 | 230 | 3 | 30 | 625 lbs | 52"L x 32"W x 38"H |
| PHW5-30024C | 4.8 | 3,000 | 10.0 | 460 | 3 | 16 | 635 lbs | 52"L x 32"W x 38"H |
